SHIFT SHAFT

Figure F-2
for Model # BFT60A
(Click Item # for details)

Price Display

(1) LINKAGE, PIVOT(2) ROD COMP., THROTTLE(3) LINK, THROTTLE(4) PLATE COMP., THROTTLE(5) PLATE, REMOTE CONTROL CABLE(6) COVER, REMOTE CONTROL CABLE(7) ARM, THROTTLE(8) WASHER, PIVOT(9) SPRING COMP., CLICK(10) SPRING, CLICK ASSIST(11) ARM, SHIFT(12) PLATE, SHIFT PIVOT(13) PIVOT, SHIFT(13) PIVOT, SHIFT(14) PIVOT, SHIFT SLIDE(15) PLATE, LOCK(15) PLATE, LOCK(16) BRACKET, SHIFT LINK(17) HOLDER, SEAL(18) SHAFT COMP., SHIFT(19) BUSH A, COVER LOCK(19) BUSH A, COVER LOCK(20) BOLT, FLANGE, 6X18(CT200)(21) BOLT, FLANGE, 6X16(21) BOLT, FLANGE, 6X16(21) BOLT, FLANGE, 6X16(22) BOLT, FLANGE, 6X11(23) BOLT, FLANGE, 6X12(24) WASHER, SIDE, 14MM(25) WASHER, SHIFT SHAFT(26) WASHER, PLAIN, 6MM(27) WASHER, 14MM(28) WASHER, 13MM(29) WASHER, NYLON, 8MM(29) WASHER, NYLON, 8MM(29) WASHER, NYLON, 8MM(30) WASHER, PLAIN, 8MM(31) CIRCLIP, EXTERNAL, 12(32) PIN, SNAP, 6MM(32) PIN, SNAP, 6MM(33) PIN, LINK(34) PIN, SHIFT LINK(35) PIN, LINK(36) OIL SEAL, 14X26X6(37) SEAL, WATER(14X26X8)(38) O-RING, 26.9X2.4(NOK)(40) COLLAR, 6MM(41) NUT, HEX., 5MM(42) E-RING, 4MM(42) E-RING, 4MM(43) E-RING, 6MM(44) E-RING, 12MM
